Key Features:

  • Fully automatic sliding door (single / double door)
  • Pre & post vacuum using a superior and low- noise liquid ring pump
  • Option of integrated steam generator or connecting to external steam source
  • Chamber and loading trays of SS 316
  • Option of trolley(s) and carriage with trays
  • Passes Bowie Dick Test
  • Built-in validation port for self-calibration checks
  • Chamber manufactured and tested as per ASME guidelines
  • Conformance to national & international standards
  • Multi-colour touchscreen Graphical Programmable Logic Control (PLC)
  • Corrective action on power failure
  • Option of 21 CFR Part 11 Compliant Software

Model #7461-0324-SU1G #7461-0432-SU1G #7461-0540-SU1G #7461-0648-RS1G #7461-0864-RS1G
#7461-0324-SU2G #7461-0432-SU1G #7461-0540-SU2G #7461-0648-RS2G #7461-0864-RS2G
Capacity (L) 324 432 540 648 864
Chamber Dim (mm) 600 x 600 x 900 600 x 600 x 1200 600 x 600 x 1500 600 x 900 x 1200 600 x 900 x 1600
Door

Single Door - for models ending with '1G'

Double Door - for models ending with '2G'

Max Operating Parameters 206.8 kPA (30 psi) / 135˚C / Vacuum

For utilities required and other technical specification, kindly contact the company representative for further details.

For models with external steam source, replace the suffix 'G' in model number with 'E'. For example – if model
#7461-0324-SU1G is desired with an external steam source (instead of a built-in steam
generator), the model would be #7461-0324-SU1E.

Due to continuous improvement in design, the product supplied may have modified features.

All electrical appliances work on 415 VAC, 50 Hz, 3 Phase + 1N. Other Voltages available on request.
