Applications:

  • Unique single lever locking mechanism for effortless locking
  • Pre & post vacuum using a superior and low-noise liquid ring pump
  • Option of inbuilt steam generator or using Customer site steam source
  • Touch screen Graphical Programmable Logic Control with preset library of cycles
  • Detailed print of cycle parameters
  • Corrective action on power failure
  • Bowie Dick Test
  • Conformance to national and international standards
  • Chamber and loading trays of SS 316
  • Chamber designed and tested as per ASME guidelines
  • Built-in validation port for self calibration checks
  • Optional EQUISOFT 21 CFR Part 11 Compliant Software

Model Capacity Chamber Dim Steam Source Max. Oprtng. Prmtrs.
#7461-0075-CH1G 75 L Ø 400 x 600 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0138-CH1G*† 138 L Ø 400 x 1100 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0138-CH2G*† 138 L Ø 400 x 1100 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0216-CH1G*† 216 L Ø 500 x 1100 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0216-CH2G*† 216 L Ø 500 x 1100 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0255-CH1G*† 255 L Ø 500 x 1300 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum
#7461-0255-CH2G*† 255 L Ø 500 x 1300 mm Inbuilt Steam Generator 206.8 kPA (30 psi) / 135ºC / Vacuum

* External steam source option available in 138L, 216L & 255L

† Double Door available in 138L, 216L & 255L

Supply: 415 VAC, 50 Hz, three phase.
